Hello list,
I just burned the latest UHD firmware onto the SD card I am using with
my
USRP2, and when I use the “uhd_find_devices” command I am told that no
devices are found. Previously I had been using the stock firmware and I
could find the USRP2 by using the ‘find_usrps’ command. When I use the
‘uhd_find_devices’ command the orange light on the Ethernet port (on the
USRP2) lights up briefly and then nothing happens. When I boot up the
device
I get a sequence of three LEDs lighting up then a flash and the right
bottom
two light remain lit. Any help with this matter would be appreciated.
Thank you,
Brenden
Am 10.08.2011 um 18:13 schrieb Brenden S.:
Hello list,
I just burned the latest UHD firmware onto the SD card I am using with my USRP2,
and when I use the “uhd_find_devices” command I am told that no devices are found.
Previously I had been using the stock firmware and I could find the USRP2 by using
the ‘find_usrps’ command. When I use the ‘uhd_find_devices’ command the orange
light on the Ethernet port (on the USRP2) lights up briefly and then nothing
happens. When I boot up the device I get a sequence of three LEDs lighting up then
a flash and the right bottom two light remain lit. Any help with this matter would
be appreciated.
Thank you,
Brenden
Your SD card seems to boot ok. The problem may be the network settings
at the host.
The old version used raw ethernet frames, so only the correct network
device ethX was required. However, the new version uses standard IP, so
you have to set the network parameters correctly, as described in
http://www.ettus.com/uhd_docs/manual/html/usrp2.html#setup-networking
You need to be in the right network (192.168.10.0/24) to find the USRP2.
Regards,
Matthias
Thank you two for the prompt reply. I had forgotten to set the static IP
address and once I did the problem resolved. Thank you again
Brenden
On Wed, Aug 10, 2011 at 11:54 AM, Matthias W. <
